The ultimate cinematic experience
LIGHT ENGINE
DLP® Type:: 3 Chip DMDs 0,95” 1080p DC4
Resolution:: 1920x1080 pixels
Lens:: High quality, high resolution improved optics with motorized zoom and focus adj.
Special features:: Puremotion 3D technology
::Puremotion 2D for fast action materials
::Puremovie 2D
Contrast ratio (Full ON/ Full OFF)::>10,000:1
Lamp power consumption:: 280W, dimmable to 230W
Brightness(1):: up to 3000 Ansi Lumens (in 2D mode)
Lamp life expectancy(2) :: 2000 hours typical in standard power mode; 3000 hours in ECO mode
INSTALLATION
Throw ratio standard lens:: 1.82-2.48:1 (type T2)
Throw ratio optional lenses:: 1.37-1.66:1 (typ. T1)
::2.6-3.9:1 (typ. T3)
Optical shift:: Vertical up to +50%, down -10% max. from screen center (based on image height)
Digital keystone adjustment:: +/-18˚
Picture size (inches diagonal):: 50-300
Aspect ratio:: 4:3, 16:9 Anamorphic, LetterBox, Panoramic, Pixel to Pixel + 3 custom-user adjustments ELECTRONICS
Horizontal & vertical scan freq.:: 15-80kHz/24-120Hz
SDTV:: PAL (B,G,H,I,M,N,60); SECAM; NTSC autom. selected
HDTV:: 480p, 720p 50/60, 1080i 50/60, 1080p 24/50/60 + 576p
PC graphic standard:: VGA, SVGA, XGA, SXGA, UXGA, WUXGA 10 bit Full Channel Signal Board Video Processing INPUTS/OUTPUTS
Digital:: 2 x HDMI-HDCP (HDMI)
Analog::1 x Composite Video (RCA)
::1 x S-Video (Mini DIN 4pin)
::1 x Graphic RGBVH (VGA-UXGA) (D-sub 15 pin)
::1 x Component - Analog YPbPr/RGBs/RGBHV (RCA)
Control:: 1 x RS232 (D-sub 9 pin)
::1 x USB
Miscellaneous:: ::3 x 12V 100mA out (via Jack) GENERAL SPECIFICATIONS
Software control:: upgradable via RS232, serial interface or USB
Mains voltage range:: 100-240 +/-10% (48/62 Hz)
Projector Weight:: 11 Kg. or 24.3 lbs
ACCESSORIES
Supplied:: SIM2 Visus System including 4 pair of active 3D glasses
::Installation and User Manual
::AC power cords (2m - 6.6 ft)
::Backlit remote control and batteries
::Live Colors Calibration software
Optional::Projector ceiling bracket (cod. LUMISBRKT)
::Anamorphic lens systems (fixed or motorized) CABINET COLORS
Standard:: Soft-touh Matte Black
(1) ANSI Lumen Specification: This is the typical projector brightness specification found in most sales literature. This measurement allows for direct comparison with other manufacturer’s projectors. Measurements are taken in a totally dark test room with T3 type lens (wide angle zoom settings), brand new lamp at full power, lamp’s native white color temperature, internal test pattern (full white) and in compliance with ANSI IT7.228-1997 specification. (2) Lamp life: the hours quoted have been measured in a lab under ideal test conditions. Lamp life varies depending on usage conditions and the surrounding environment. This is an average value that cannot be guaranteed and is not protected by warranty. The DLP® logo and DLP® medallion are trademarks of Texas Instruments. Due to constant product development, specifications are subject to change without notice.
