Resolution, Power, and Color
LIGHT ENGINE and DISPLAY (x single projector)
DLP® Type and image resolution::1-chip DMD 0.67” UHD - 4K UHD (3840x2160 pixels) - 8.3M pixels
Dynamic Range::HDR compliant, with dedicated Display Modes and 4 presets to cover the screen sizes
Lens::Super high definition pure-glass lens with telecentric optics
Lens resolution::93 lines per millimeter
Light Source and brightness(1)::2x 450W lamp (dimmable) - up to 10,000 Ansi Lumens
Lamp life expectancy(2)::3000 hours typical in ECO mode
Adjustable iris::10 apertures memorized
Autofocus tracking
Remote Info function::SIM2 Customer Care 4
Live Colors Calibration 4.0 INSTALLATION
Lens Throw ratio (+/-5%)::1.36-2.68:1
Zoom & Focus::Motorized with position encoders
Optical Shift::+/-75% Vertical, +/- 30% Horizontal ELECTRONICS AND CONNECTIVITY
Horizontal & vertical scan freq.::15-91kHz/24-120Hz
UHD::@ 24/25/30/50/60/70/72/75 Hz
HDTV::480p, 720p 50/60, 1080i 50/60, 1080p 24/50/60 + 576p
PC graphic standard::VGA, SVGA, XGA, SXGA, UXGA, WUXGA, UHD, 4K (4096x2160), 10 bit Full Channel Signal Board Video Processing
Color Calibration::Live Colors Calibration software 2.0 INPUTS/OUTPUTS (x single projector)
Digital::2x HDMI (v.1.4a - HDCP 1.4)
::1x HDMI (v.2.0a - HDCP 2.2)
::1x HDMI audio/video out (v.1.4a - HDCP 1.4)
::1x Display Port 1.2
Analog::1x VGA / 3x YCrCb Component
Control::1x USB (A type - FW UpGrade)
::1x RJ45
::1 x RS232 (D-sub 9 pin)
::2x IR receivers
::1x wired IR receiver
Miscellaneous::2 x 12V 200mA output GENERAL SPECIFICATIONS
Horizontal & Vertical scan freq.::15-91 KHz/24-120 Hz
UHD::@ 24/25/30/50/60/70/72/75 Hz
Mains voltage range:: 100-240 +/-10% (48/62 Hz)
Single projector Weight:: 32 Kg. / 70.5 lbs
Single projector dimensions:: 528 x 215 x 582 mm (20.8” x 8.5” x 22.9”) ACCESSORIES
Supplied::Installation and User Manual
::AC power cords
::Remote control and batteries
Optional::Projector ceiling bracket
::Anamorphic lens systems (fixed or motorized) (1) ANSI Lumen Specification: This is the typical projector brightness specification found in most sales literature. This measurement allows for direct comparison with other manufacturer’s projectors. Measurements are taken in a totally dark test room, brand new lamp at full power, lamp’s native white color temperature, internal test pattern (full white) and in compliance with ANSI IT7.228-1997 specification. (2) Lamp life: the hours quoted have been measured in a lab under ideal test conditions. Lamp life varies depending on usage conditions and the surrounding environment. This is an average value that cannot be guaranteed and is not protected by warranty. Due to constant product development, specifications are subject to change without notice.
